L-Blocks

L-Shaped Concrete Block?

  • Very versatile
  • Is designed so that it is self-supporting. The higher up the face you have the product or materials, the more the weight of the product is sitting on the foot and supports the weight against the face.
  • Is fully engineered, so they can be used for multiple purposes
  • They are available in a tapered or stepped configuration for a neat finish.
  • No footing or concreting required – only a compacted level base for the blocks to sit on.
  • They can be backfilled as soon as the blocks have been bolted together and sealed.
  • Custom sizing is available – ranging from 600mm to 2400mm high, 700mm to 1000mm foot, and 1000mm to 2400mm wide.
  • Corner blocks also available – 45 degree, or 90 degree.

What Is An L-Shaped Concrete Block?

L-shaped concrete blocks are our most versatile product thanks to their innovative design. Named so for its L-like shape, the L-Block features a longer upright section (called the face) connected to a lower and shorter supporting section (called the foot), which carries the weight.

This concrete product is entirely self-supporting and comes in clean, durable modular panels that can be custom-designed and constructed to fit your specific needs. Face finish designs are also available for a more aesthetic look, which can come in patterns or textures.

What Are L-Blocks Used For?

Due to their very simple design, L-Blocks can be used for virtually any application, mostly either for retaining or containing purposes. So far, we’ve installed L-Blocks for uses such as:

  • Retaining walls
  • Shed walls
  • Silage Pits
  • Ramps
  • Dividers
  • Loading docks
  • Bunkers for hay, silage, and fodder
  • Storage walls for Grain, Fertiliser, Almond Hulls, etc.
  • Waste recycling

And much, much more

We’ve found that L- Shaped Concrete Blocks are truly multi-purpose and versatile in function. Vikon Precast’s L-Blocks are all pre-cast and specifically engineered to fit your requirements, whether it’s for use in your backyard or in a large agricultural complex.

Features Of L-Shaped Concrete Blocks

One of the best things about L-Blocks is that they are available in different styles, depending on what you or your business needs. Vikon Precast offers both tapered or stepped blocks in a smooth, sleek finish. Each block is locked together using a 10mm galvanised locking plate at the back of the panel which creates one solid wall.

Most important of all, L-Blocks are incredibly easy to install. No concreting or drilling is required. Only a compacted level base for the blocks to sit on- ensuring the ground has a load bearing pressure of 150kPa. This results in an extremely fast and cost-effective solution and takes very little time to complete installation.

Sizing

Vikon Precast offers custom sizing for L-Blocks. Just contact us with your design requirements and sizing, and we will design the blocks to accommodate your needs. Our sizing parameters are:

  • Height: 0.6m to 2.4m
  • Foot: 0.7m to 1m
  • Width: 1m to 2.4m

We also offer corner blocks in both 45 and 90-degree angles.
